WiFi Express - 30503000 HOBBYWING  [HW-30503000]

WiFi Express - 30503000 HOBBYWING [HW-30503000]

SKU: HW-30503000

ntuitive InterfaceThe Wifi Module is a complete different concept from the way the HOBBYWING LCD program box works, all the parameters of the wifi module are displayed all in one via the graphical and interactive interface with dropdown menu's and scroll bars. Now users can program their ESC in a much more user friendly interface without delay.

Firmware UpdateWith this WiFi module, the end users can easily and promptly update the firmware of their ESC via their smart phone (with the HW LINK APP), which eliminates the use and carriage of a laptop pc.

Compact DesignThis WiFi module is smaller,smarter,lighter and only 1/6th of HOBBYWING LCD program box in size and weight. It has a hardwired programming cable to connect to the ESC not like the lcd program box which needed an extra programming cable to connect to the ESC.

One-touch Factory ResetUsers can promptly factory reset their WiFi module via the Reset button at the bottom of the case.



  • Specifications:



    Product SpecificationSpecifications

    • Working Voltage : 5V-12.6V
    • WiFi Protocol : IEEE802.11 b/g/n
    • WiFi Signal Effective Range : 0-10m (Open Field)
    • Size : 25.7x25.7x8.8mm (LxWxH)
    • Weight : 11g


    Applications

    • XERUN series & EZRUN series of car ESCs.
      PLATINUM series of aircraft ESCs.
      SEAKING PRO series of boat ESCs.
      Other ESCs which are compatible with HOBBYWING multifunction LCD program box
84,99AU$Price
